89mm Vertical Blinds Weight Socket

A plate socket for weighing down vertical blind curtains
24m
1× print file
0.20 mm
0.40 mm
4.00 g
Elegoo Neptune 3 Pro
2
32
0
178
updated January 26, 2024

Description

PDF

Using the original design (thanks to Irgendeintyp), I turned it into a socket to repair the broken parts. In this form, the weights were reused by cutting the broken handles and trimming the edges. This saved printing time and filament greatly. The weight close to the original was also preserved.

Sample configuration (for just one sample):

3D Printer: Elegoo Neptune 3 Pro
Filament: PLA+ White

Slicer: UltiMaker Cura
Resolution: 0.2mm
Infill: 100%, Grid
Wall Line Count: 2

Support: No
Adhesion: Yes (Recommended, because the edges may curl up when printing in large numbers and for long periods of time)

Time: 24m
Weight: 4g (1.48m)

Comments: Have repaired about 40 of them with this method, which had become dry and brittle due to exposure to the sun. Very practical as it does not require gluing etc. The result was satisfactory.

Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

  • The original design was transformed into a kind of socket.
  • Existing weights can thus be reused by cutting off broken handles and trimming the edges.
  • This can greatly save printing time and filament.
  • Weight close to the original is also preserved.

 New dimentions: 101mm x 19mm x 6mm (For 89mm x 50mm size weights)
