Companion Cube - Box

This Companion Cube consists of separated parts to be able to print it with different colors and to use it as a storage box (hollow space: 99x99x99mm).

The parts made from the original model were not really symmetrical and so I made a few adjustments.

Print Settings

Printer Brand:

Prusa

Printer:

i3 MK3

Rafts:

No

Supports:

No

Resolution:

0.1mm

Infill:

10%

Instructions

You need the following quantity to build this Companion Cube (color/material is your choice off course):

6x Body_plate

6x Heart_insert

6x Heart_medal

8x Edge

12x Angle

In my case, I was simply able to press (with a bit of force) the Heart_insert parts into the Heart_medal. The same applies to the medals and Body_plate (rotate the medal in about 90 degree steps if it does not fit).

Tip: print each part once and test if this works. Otherwise process (rescale for example) the parts accordingly.

The optional sticking_tool_top and *_bottom are used to fix the plates and edges after applying glue on them (look at the photos to get the idea).rn

Category: Video Games

Used original to split it into separate parts. Applied some symetrical fixes as well.
