parametric Smartphone Holder for Cooler Master Qube 500

You want a Smartphone holder that fits your phone with its case? Here it is!
7
17
0
174
updated December 9, 2024

Description

PDF

There are many smartphone sizes and even more cases. To fit your specific combination print your own suitable Smartphone holder for the Qube 500 with this model!

What you need:

  • Filament of your Choice
  • 4 pieces M3x8 Flat Head Screw
  • 4 pieces M3 Hexnut
  • some Coffee or Beer while watching the print ;)

Instructions:

  1. Adjust the height, width and depth of your Smartphone in the .step-File at the Parametric Section. I use Fusion360. See Photo.
  2. Export the adjusted Part “Smartphone_plate”
  3. Print the Part “case mount” once
  4. Print the adjusted Part “Smartphone_plate” once
  5. (optional) print the Part “bumper” twice. In TPU for the best dampening.
  6. Insert the four Hex-nuts at the "case mount"-part
  7. Screw the “Smartphone_plate” with the four Flat Head Screws to the “case mount”-Part
  8. If you wish you can glue the “bumper” to the back of the “Smartphone_plate”. Attention to the cutouts from the Qube 500.
  9. Mount the assembly to the case
  10. Put your Phone in
