Skadis mount for 7" Touch Screen Display

After getting a 7" Touch Screen Display for my Raspberry Pi's I wanted a frame for it that I could hang on Skadis.
20
52
1
1062
updated March 18, 2021

Description

PDF

Found this frame for the 7" Touch Screen Display and it fits the screen like a glove and still allows for menu buttons to be used, great design. Only thing that would make this frame perfect for me would be having a bracket to hang it on Skadis Pegboard.  So I made one.  I used the hooks from this Headphone hanger, https://www.thingiverse.com/thing:4784771.  Thanks for the great design.

You can find the frame for the display here: https://www.prusaprinters.org/prints/46236-7-touch-display-frame.

Printed on Prusa Mk3S at .20 layers.  Printed the print upside down and used supports from build plate.

I was very impress with how the hooks work on the Head phone model which is why I used them for this print.
