Retaining Blocks for Ø4 mm Wire (surface mounting, screw-on)

Designed for retaining wire mesh panels. Could also be used for cables of 4 mm OD, if nail-on clips are inadequate.
5
19
1
106
updated October 6, 2023

Description

PDF

Designed for retaining wire mesh panels.
The larger one has a side notch to accommodate the weft wire.

These might also be used to retain DC electrical & USB cables of 4 mm OD, for example if nail-on clips are inadequate for your application.

Screw size :  Ø3.5 woodscrews

FreeCAD source model :  See reference application
https://www.printables.com/model/601126

Tags



Model origin

The author marked this model as their own original creation.
