60mm to 40mm fan adapters.

Two different options for mounting a 60mm fan in place of a 40mm fan.

One is center point alignment.

The other is a shared corner point.

The one that shares corners fits the Hero Me Gen6 base. I think it should also fit the Hero Me Gen 7 base as well. This is assuming that you are only trying to run a single fan on one side and rotate the adapter to clear the blower fan.

 It does clear a 5015 single fan dual duct setup on Gen 6 Thats what I have it installed on.


--------- Notes ----------
The M3 holes are a slip fit to bolt it to what ever part you need to.

The M4 holes for the 60mm fan are sized so the screw cuts its own threads.

The shared corner fan adapter the screw hole on the shared corner does not accept a M4 screw the hole is to large. This is so the M3 can be passed through to the bottom.  Sacrifices had to be made.  (I have super short one screwed through my fan grill in the picture because it was bothering me…)

<> Inspired by this fan adapter, which is a shared side but didn't work for my use case. <>
