Lack Enclosure Drawers - Prusa Mini Edition

PRUSA MINI EDITION

Is your print enclosure "lacking" storage? Well I have the solution for you! The Lack Enclosure Drawer unlocks the incredible enhancement of storage for your enclosure in a new and exciting way.

*Also works great as an addition to any workbench

Features:
• Seamless alignment for that oh-so-clean look.
• Lack Drawers also include optional slots for magnets (20x5x2mm) allowing drawers to snap into place with a nice "Click"

Print instructions

INTRO
These drawers can be configured in a number of ways. To simplify assembly the drawer cases are alphanumerically identifiable.
• R1M and R2M cases are design only for drawers on the right side end.
• In a stacked arrangement A1M and R1M are all considered top row while A2 and R2 are considered second row.

HARDWARE
• Screws: 3x12mm wood screw or #4 x 3/4 inch screws
• M2x6 Screws and M2 nuts (Used for attaching rows of drawers together)
• Drill bit that is smaller diameter than the wood screws
• 20x5x2mm Magnets

INSTRUCTIONS
• Use printed templates to mark the hole locations on the surface you are mounting the drawer case to.

• Drill out marked locations

• Make sure optional magnets are installed into drawer case


• Screw drawer case in place using 3x12mm or #4 x¾ inch wood screw.

• Insert magnets into drawer and slide in place. (If the magnets are opposing rather than attracting you need to reinstall them facing the opposite direction.)


• If installing second row of drawers you will need to insert the M2 nuts into the hex slots on the A1M or R1M case. (Using a long M2 screw threaded into the hex to pull it in place is an easy way to do this.)

• Attach A2M or R2M cases to the above hex nuts using M2x6 screws

NOTE: all drawer cases will work fine if a single row of drawers is desired.

Filament: PLA (PETG or ABS for heavier duty storage)
Nozzle Size: 0.4mm
Print Height: 0.2-0.35mm
Infill: 10-20%
