KTM/HQV 450/500 Marking Mandrel Pt.# 78129032000

This is a re-created version of KTM/Husqvarna "Marking Mandrel" Pt.# 78129032000 intended for timing the balancer shaft when re-installing the side case on a KTM 450/500 or Husqvarna 450/501.

Here's a YouTube video explaining the process:


If you want to compile the part in openscad you require these dependencies:

• threadlib: https://github.com/adrianschlatter/threadlib
• Knurled Surface Library: https://www.thingiverse.com/thing:32122

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

No

Resolution:

0.15

Infill:

35

Filament:

AMZ3D 1.75MM PLA White


Notes:

I printed with 3 walls just to make it stronger. I would encourage 0.15 or lower resolution because of the threads. I used a brim to ensure adhesion, you do what's best for your printer.

Category: Machine Tools
