MagSafe insert for Audi A6 C6 Centre Armrest

Replaces the plastic adaptor plate in the centre armrest.

USB cable is routed in place of the exiting wiring, through the hinge assembly of the armrest. You can remove the rear air vent to gain access to the wiring and to the single bolt holding the armrest in place.

The hole is sized for the following MagSafe adaptor I bought https://www.amazon.co.uk/gp/product/B09MJW72CS

Printed in PETG, with standard settings on my MK4.

0.4mm nozzle
15% infill

I printed it upside down, with supports which peels off very easily (at least on PETG). The supports are only needed for the centre hole. I have not yet tried printing without support, it's possible it will work.
