Screw Measuring Tool for Cooler Master QUBE 500
Measure your metric fasteners from the convenience of your Qube!
In the contest Cooler Master QUBE 500 - PC Case Accessories
17
79
4
568
updated September 29, 2023
Description
PDFThe “A” version uses one clip and aligns with the center of the grid holes. The “B” version uses two clips and aligns with the center of the dividers (see picture).
The heat inserts are M3x4mm, and the screws are M3x6mm flat head.
I used organic supports under the tab of the clip, otherwise no supports needed.
Don't forget to add the color change layer for the numbers on top!
Tags
Model origin
The author remixed this model.
Screw measuring tool, M2-M10, 4-120mm
by BoogieThis source model was used for remixing before its license was restricted.
Differences of the remix compared to the original
Shortened and adjusted scale to match standard metric screw lengths. Added mounting holes to add on a clip to fit the Cooler Master CUBE 500 case, as well as re-sized to match the grid.
