Self-Guided Projectile

A small self-guided projectile that I've been working on. Uses basic electronics and Python.
22
55
0
787
updated October 1, 2023

Description

PDF

This is the first “large” file or project I've done and uploaded.

Everything except the nose cone should be printed in rigid filament, most testing was done with ABS. The nose cone should be printed with TPU.


A 2-in. diameter projectile that uses basic electronics and Python OpenCV to automatically adjust trajectory towards a colored target, which is blue in my base code.
Planned to fire out of a potato cannon.
I'm not actively working on this, so updates will be slow.
Also if anyone has suggestions on how to move the fins within the structure of the projectile, that would be great, I just don't have the time to put in to redesign that system.
