Voron Trident A Drive Umbilical Guide

Fits a 16-cable umbilical and a shielded usb cable. Designed to mount to a Voron Trident A drive.
68
337
3
2419
updated September 26, 2023

Description

PDF

I designed this simple mod to hold and protect the umbilical cable I run to my Voron Trident toolhead. This guides the wires down through the slot in the A-Drive so that they can be safely routed to the electronic bay at the bottom.

The two halves are already oriented for printing. Use a minimum of 3 walls and 20% infill for a 0.4mm linewidth. 2 walls are OK for 0.5mm+ linewidths. Add m3 inserts to the cavities in the smaller part, and use m3x16 bhcs to attach the halves together. It can be mounted to the A drive with another m3 bhcs/shcs.
