Hummingbird Feeder Replacement Parts

Replacement parts for your sun-damaged hummingbird feeder.
In the contest Replacement parts
25
175
0
706
updated September 27, 2023

Description

PDF

My hummingbird feeders were getting quite sun damaged, so I designed some replacement parts to fit the original glass bottle. The glass bottle is from the Perky-Pet 16oz hummingbird feeder, model 204CP-4, though I've included the F3D file for editing if you have a slightly different one.

I did redesign the bottom so that the flowers and spouts are much easier to print. They also have notches so they all align properly.

Printing details:

  • 0.25mm layers using a 0.6mm nozzle ("structural" setting on the Prusa MK4), though it'll work just fine with other layer heights.
  • 100% infill (there's very little) for waterproofing.
  • 3 perimeters.
  • Recommend printing in PETG or any sun-resistant filament (I used Overture's red and green PETG).
  • Supports are only needed on the underside of the “Top” piece to support its roof.
  • You need 5 of the flowers, print them with the top (the visible surface) on the build plate.
