Gehäuse für das BTT Manta M5P-Board. Im Deckel ist Platz für zwei 40mm Lüfter für die Stepperdriver und ein 60mm Lüfter
11
116
1
696
updated July 8, 2024

Description

PDF

Gehäuse für das BTT Manta M5P-Board.

Im Deckel ist Platz für zwei 40mm Lüfter für die Stepperdriver und ein 60mm Lüfter für das CM4/CB1 Modul.

In die 4mm Löcher zur Verschraubung des Boards und des Deckels kommen M3 Gewindeeinsätze. Ich verwende Ruthex-Einsätze. https://www.ruthex.de/collections/gewindeeinsatze/products/ruthex-gewindeeinsatz-m3-100-stuck-rx-m3x5-7-messing-gewindebuchsen

Case for the BTT Manta M5P Board.

There is place for 2 40mm fans for the stepper driver and one 60mm fan for the CM4/CB1 modul.

Place M3 brass inserts in the holes for screwing the board and the cover. I use Ruthex inserts. https://www.ruthex.de/collections/gewindeeinsatze/products/ruthex-gewindeeinsatz-m3-100-stuck-rx-m3x5-7-messing-gewindebuchsen

Print Settings

Printer:

AM8 MGN

Rafts:

No

Supports:

No

Resolution:

0.2 mm

Infill:

25%

Category: 3D Printer Parts
