Prusa Mini Z-Axis Modification

Diseño robusto, esperemos mejor los resultados de impresion.

Great design. Printed parts in ASA (voron spec) to add some stiffness. Don't min the cut away parts of the prusa mini base, it still works. Instructions would be nice to ensure things are tightened in the correct order. Using the skew test here https://www.printables.com/model/70792-easy-3-axis-skew-calibration-tower-with-spreadshee I achieved max 0.15mm deviation on all measured lengths, just as a reference for anybody else. (edited)

Where to get the .slt for the extruder cap please? I cannot find it...

Please can you send me a list of screws etc what you used? Minimal lenght of profile isnhow many mm? Also the cap for profile, what type is it? Thank you

Hi, can you, please, provide step file for plate as well in case someone would like to have the plate CNC machined?

Could you provide stl for the sensor, please? (edited)

will test further, hopefully, it's going to work (edited)

Please add in details that this modification causes the test z-axis to fail because the thickness of the bracket and z axes becomes longer. I was confused at first why test always fails (edited)

Successfully fix the XZ skew on my MINI clone.Thanks!

Hello, is the extra length on the extrusion to hold the filament roll, or does it add rigidity? If it is only to hold the filament roll, what is the minimum recommended length? I am trying to have my printer keep the small profile so it may fit in my enclosure. Thank you!
