Wall Mount Screwdriver Holder 7 Slots

This is a screwdriver holder which mounts to a wall for storing screwdrivers
1
50
1
170
updated September 20, 2023

Description

PDF

This is a remix/combination of the two holders from @Scrappy79.  I needed a couple more slots, but didn't want two separate holders.

I imported into Fusion, did a planar cut on the “large” file to remove three of the slots, merged the small with the now-cut large, cleaned up the fillets (that were now in the middle), removed a keyhole, and added a rib.

I'll add a real picture after I print it…

Model origin

The author remixed this model.

Differences of the remix compared to the original

Took the two “V1” files, removed 3 of the holes from the large one, combined it with the small holder.  Removed a now extraneous keyhole mount slot and added another support rib.
