Don't you know how you install a new lamp in your dinig room and while fixing the cable, the tiny relief clamp breaks?

But thats why we have a 3D printer, right? At least thats what I thought and so I designed a parameterizable bracket that can be easily adapted to your needs via Fusion360. To make it more convenient for you, I have provide the f3d file for download.
Simply change the parameters, export as STL and print. About 15 minutes of work and you can continue with your project!

Here is an overview of all the parameters of the draft:

This are the dimensions I used to repair the clamp in the dining room lamp. After a few minutes I could continue and my wife now sees some more use in my 3d printer.
I printed it at 100% infill and used PLA+. Maybe another material like ABS or ASA is better, but my print has lasted for more than a year.

I would love to see what you fixed- so please post your Makes!

If you have any suggestions for improvement, just make comment.
