PS4 Controller Universal Phone Holder

Remix of Paga777i model.
51
323
6
1658
updated September 12, 2023

Description

PDF

Remix of Paga777i model.

I've take a shot on this project and made a new back piece for a better usage. Now it comes in 3 different parts that should be assemble together. It's also more strong and makes a better overall feeling all along the back of the controller. The hinge makes putting on and taking off very simply the mount from the controller and make it a lot stable.

New front part design: Better feeling in hands, now it's easier to press the share and options buttons, no more always pressed touchpad (now you can really use it).

For the hinge assembly I used a piece of filament melted on the ends, but you can use any 1.75mm < Ø < 2mm (20mm length) pin. For the ring simply deform it a bit until it goes trough the hole and then push hard until it clicks (see images), repeat for the other side. The back piece should deform a little in the upper part to make its way in the holes of the front piece.

For the last part take a medium size rubber band and put it between the top and the front piece.

Have a nice game!



Print Settings

Rafts:

No

Supports:

Yes

Resolution:

0.2/0.15

Infill:

50% with 5 perimeters

Filament: Anything you like




Notes:

The front (both old and new), the top and the hinge need supports. For the others I suggest using brim.





Category: Video Games

Tags



Model origin

The author remixed this model. Imported from Thingiverse.

PS4 Controller Phone Holder
by Paga777i (thingiverse.com)

Differences of the remix compared to the original

New hinge part that makes putting on and taking off very simply and make it a lot more stable.

New front part design: Better feeling in hands, now it's easier to press the share and options buttons, no more always pressed touchpad (now you can really use it).
