Ender 3 Pro mainboard cover for 92mm fan

Got a few spare 92mm fans lying around? This is a mainboard cover for the Ender 3 Pro, allowing you to mount one.
2
22
0
178
updated September 12, 2023

Description

PDF

Quickly thrown together, this mainboard cover will allow you to mount a 92mm fan in, or on your Ender 3 Pro mainboard case, for improved or comparable cooling with less noise.


Important: I heavily recommend printing these, at 40mm height, before you take everything apart, you will need some clearance in order to fit a fan under there:
https://www.printables.com/model/482903-ender-3-risersfeet-20-70mm-versions


Goes nicely with the following models:
https://www.printables.com/model/145449-ender-3-pro-low-profile-rear-mount-for-meanwell-ps
https://www.thingiverse.com/thing:4503364 (Will require you to sandwich the PSU mount between the fan and this model, it does work though.)


Tags



Model origin

The author remixed this model.

Differences of the remix compared to the original

Now it allows you to mount a bigger, 92mm fan, with a hex mesh to stop cables from falling into it. If you have a slim 10mm fan, you may be able to mount it on the inside and have the fancy hex mesh showing, although you will never see it.
