Sunlu FilaDryer S1 3D Printing Mate

Summary (updated)

I liked the Sunlu FilaDryer S1 3D Printing Mate design and appears to be well designed, but product needs more work!

1. They need to look at filament output with a modular output option.
2. Should have a small (but quiet) circulation fan added. (working on that)
3. Humidity sensor Mount is now incorporated in the bung.

3a. Hydro Meter https://www.amazon.com/gp/product/B07GNMKYCZ/ref=ppx_yo_dt_b_asin_title_o02_s00?ie=UTF8&psc=1
So now it is starting to be more functional and easy to monitor.

They need to evaluate the cost and performance. As is a little overpriced.
Still quite functional but additions needed or required.

This is the next option I am looking at https://www.eibos3d.com/ ($125)

The thing I did not like the most was the filament options for routing out of the box.
I use the Prusa i3 MK3S with MMU2S but needed to keep the 5 filaments dry with continuous printing.
So I designed a 2 piece bung to add a new filament track out the back of the box for the PTFE tube. (also looking at other location options)
I had to drill 1/2" and 4 3/32" clearance holes for the fasteners. The Push-To-Connect will self thread into the Bung Cap.

This works great so far and I do not need the filament buffer as filament is contained in the Sunlu S1.

All files included so you can modify if needed.

I used fasteners and a Push To connect for the filament tube

1. Qty 1 - Push-To-Connect - https://www.mcmaster.com/51025K774/
2. Qty 4 - #2 Torx screw - https://www.mcmaster.com/96001A156/
3. Qty 4 - #2 Mill Spec Washer - https://www.mcmaster.com/90618A113/

Let me know what you think, leave a comment or recommendation
Thank Rich
