This is a replaceable slider part for Olfa 18mm blade knives when the screw hole on the slider becomes damaged and cannot be tightened.

I previously released a replacement part for slider part C here https://www.printables.com/model/413986-replacement-slider-parts-for-olfa-utility-knives.

However, it was also usable for the knife with slider A, but there was an issue with its appearance as some parts protruded from the knife's body. Therefore, I have designed a replacement slider that is compatible with both slider part A and slider part C.

Print settings:

Filament: PETG
Layer height: 0.2mm
Supports: No
Perimeters: 2

Required other than printed parts:

1x M4 nut

Assembly:

It's as simple as threading an M4 nut onto it.

Notes:

The terms like \u201cSlider part A\u201d or \u201cSlider part C\u201d are the designations I found on the Japanese version of the Olfa's online store. Since I couldn't find the designations for slider parts in other languages, I have used the designations \u201cSlider part A\u201d and \u201cSlider part C\u201d.
https://store.olfa.co.jp/slider
If you plan to use it in environments exposed to high temperatures, such as the interior of a car during the peak of summer, we recommend printing it with PC or ABS filament.

Compatible Knives:

","category":{"id":"49","path":[{"id":"48","name":"Hobby & Makers","nameEn":"Hobby & Makers","description":"Are you a maker? Everyone is, be a printer. Upgrade your home workshop and combine different materials and methods of crafting including 3D printing.","__typename":"CategoryType"},{"id":"49","name":"Tools","nameEn":"Tools","description":"Perfect tools and accessories for DIY enthusiasts or handicraftsman professionals. Table clamp, CNC machine parts, screw measuring tool, or multipurpose ruler.","__typename":"CategoryType"}],"__typename":"CategoryType"},"modified":"2025-02-13T13:44:43.532413+00:00","firstPublish":"2023-09-09T13:03:10.489602+00:00","datePublished":"2025-02-13T13:44:43.493933+00:00","dateCreatedThingiverse":null,"nsfw":false,"aiGenerated":false,"politicalContent":false,"summary":"This part can be replaced with both slider parts A and slider parts C.","likesCount":26,"makesCount":0,"liked":null,"printDuration":null,"numPieces":0,"weight":null,"nozzleDiameters":null,"usedMaterial":null,"layerHeights":null,"mmu":false,"materials":[],"dateFeatured":null,"downloadCount":67,"displayCount":742,"filesCount":2,"privateCollectionsCount":15,"publicCollectionsCount":16,"pdfFilePath":"media/prints/577444/pdfs/577444-olfa-utility-knives-replacement-slider-5253b74f-573f-474f-9b5a-bd420dfd2107.pdf","commentCount":1,"userGcodeCount":0,"remixCount":0,"canBeRated":false,"addMakePermission":null,"printer":null,"image":{"id":"2192365","filePath":"media/prints/577444/images/4621472_c678b141-3be9-4060-9ecf-1fe12d06a076/pxl_20230909_113646034.jpg","rotation":0,"imageHash":"ohgKDYDqioaEi4h/Z7hkfJU/Pezw","imageWidth":1485,"imageHeight":1114,"__typename":"PrintImageType"},"images":[{"id":"2192365","filePath":"media/prints/577444/images/4621472_c678b141-3be9-4060-9ecf-1fe12d06a076/pxl_20230909_113646034.jpg","rotation":0,"imageHash":"ohgKDYDqioaEi4h/Z7hkfJU/Pezw","imageWidth":1485,"imageHeight":1114,"__typename":"PrintImageType"},{"id":"2188888","filePath":"media/prints/577444/images/4613270_3ef69400-3f3c-4c43-b2b8-b0dffdc02a0d/pxl_20230909_112605282.jpg","rotation":0,"imageHash":"ZggGDYC6SHg4ZohNgGlXZOA2Cm6D","imageWidth":1485,"imageHeight":1114,"__typename":"PrintImageType"},{"id":"2188889","filePath":"media/prints/577444/images/4613272_1ed235bc-a980-4e4f-954a-80b56f53ac19/pxl_20230909_113449209.jpg","rotation":0,"imageHash":"5BgKDYC1hnhYl4efdKibd2eqQDcK","imageWidth":1485,"imageHeight":1114,"__typename":"PrintImageType"},{"id":"2189005","filePath":"media/prints/577444/images/4613460_a7d48656-2ede-475e-91d6-71edefb7fee1/pxl_20230909_132615921.jpg","rotation":0,"imageHash":"YAgODYL1qXiXeHh3iJeGfvt2uE+H","imageWidth":780,"imageHeight":585,"__typename":"PrintImageType"}],"imagesCount":4,"tags":[{"name":"olfa","id":"33535","__typename":"TagType"},{"name":"olfacutter","id":"122626","__typename":"TagType"}],"thingiverseLink":null,"filesType":null,"previewFile":{"id":"4957091","filePreviewPath":"media/prints/577444/previews/d37942f744e3874611c35b69d42b2b83bd5b2a0b.png","__typename":"STLType"},"license":{"id":"1","disallowRemixing":false,"__typename":"LicenseType"},"remixParents":[{"id":"385566","modelId":"413986","modelName":"Replacement Slider Parts for Olfa Utility Knives","modelAuthor":{"id":"174466","handle":"BaGooN","verified":false,"publicUsername":"BaGooN","__typename":"UserType"},"model":{"id":"413986","name":"Replacement Slider Parts for Olfa Utility Knives","slug":"replacement-slider-parts-for-olfa-utility-knives","datePublished":"2023-04-18T07:35:30.162646+00:00","image":{"id":"1651569","filePath":"media/prints/413986/images/3435377_0002bcce-4b8c-4242-a22f-a06c7e47b61e/pxl_20230303_104519262.jpg","rotation":0,"imageHash":"4hgKFYKjeImgaYithqiIibqPntz4","imageWidth":1280,"imageHeight":960,"__typename":"PrintImageType"},"club":false,"authorship":"author","license":{"id":"1","name":"Creative Commons \u2014 Attribution","disallowRemixing":false,"__typename":"LicenseType"},"eduProject":null,"__typename":"PrintType"},"url":null,"urlAuthor":null,"urlImage":null,"urlTitle":null,"urlLicense":null,"urlLicenseText":null,"__typename":"PrintRemixType"}],"remixDescription":"

Improved compatibility
