Clip-On Ikea Raskog / Rashult Cart Organizers

A collection of organizers for the Ikea Raskog and Rashult carts, most also work with the Ikea Skadis pegboard
In the contest Organization Tools
172
412
6
3947
updated January 11, 2024

Description

PDF

Ikea Raskog Organization Collection

Compatible with the Ikea Skadis pegboard using the “universal hook” from this set (not mine).

We have several Ikea Raskog project carts at our house and lately I've been using one as an end table. I use magnetic jars to hold on to bits and pieces but I wanted a more secure / stable way to hang organizers off the side of my carts.

Once I figured out how to make an easy to print hook that would clip firmly onto the cart's trays, I realized that I could make a hook that would be cross compatible with the Skadis Universal Hook Set. You can use the universal hook from that collection with most of the items in this collection to use them on the pegboard. And any of the items in the Skadis set that use their universal hook can be used on the Raskog with the universal hook from this collection.

Like that collection this is easy to print (no supports), easy to assemble with no glue, strong, and stable.


One-Piece Hooks


On work carts it's nice to be able to hang tools off the side. I ended up making a couple sizes as a design compromise. The "narrow" version is 4mm square and plenty strong (especially when printed with 3 perimeters) to accommodate things with smaller diameter hanging holes.

The wide hooks are 12mm wide which makes them more stable especially for things that might swing.

Note: Since these are are single pieces they are not compatible with the Skadis pegboards or that set.

Features
  • Four varieties
    • Narrow Half-Round
    • Narrow Quarter-Round
    • Wide Half-Round
    • Wide Quarter-Round
  • No assembly required


Hook Row

The narrow one-piece are as small as I could make them and still maintain lateral stability but I also wanted an option for even small hooks. Enter the hook row.



Features
  • Four small diameter hooks.
  • Three small gaps between the hooks.
Requires
  • 2 Universal Hooks



Nintendo Switch Holder


As I said, I use a Raskog like an end table so I wanted a store my switch so it would be in easy reach. I also rarely put the console in it's dock so I wanted to allow for a charging cable to be attached.



Features
  • Can hold the Switch while a USB cable is attached.
  • Holds the console with or without the Joycons attached.
  • Stabilizers to guard against side-to-side movement.
  • Four game cart slots behind the switch.
Requires
  • 2 Universal Hooks.

Pen Holders

I wanted a pen holder that would work for any pen, Sharpie diameter or smaller. I found it easier to get pens in and out when the holder was angled a bit but I could see how that may now always be desirable. So I made two versions.


Features
  • Two versions:
    • Vertical
    • 22° Angled Version
  • Holds four pens.
Requires
  • 2 Universal Hooks.
  • Pens or devices of similar dimensions:
    • brushes
    • pencils
    • glow sticks


USB Cable Holder


I wanted a holder for the end of various charging cables that was also able to accommodate some of the bigger dongles and doodads. My first attempt was too big for my narrow cables and too small for my really thick cables. I ended up making two widths of slots to handle the many whims of cable manufacturers.



Features
  • Four wide cable slots.
  • Three narrow cable slots.
  • Two USB-A slots.
    • For thumbdrives, adapters, and such.
  • One USB-C slot.
  • Deep tray for holding widgets.
Requires
  • 2 Universal Hooks.



Print Settings

As Pictured

  • 0.4mm Nozzle
  • 0.15mm layer height
  • 10% infill
  • 3 perimeters
  • PLA
    • Printed Solid Jessie
    • Feta Green

Tags



Model origin

The author marked this model as their own original creation.
