Wall mounted rack for AK INTERACTIVE Real Colors Set

3D printed parts

Modular, expandable holders for two paint cans of the same type.
The bracket is divided into two half-shells, which means that no support structure is required. The two half-shells are connected using adhesive and screw clamps. Be careful, too much pressure with the screw clamps results in deformation.
The angle of inclination and the low static friction due to the rails allow the rear paint can to slide automatically when the front paint can is removed.
The slot on the front allows the article name to be inserted.
A hole in the middle of the bracket allows it to be attached to a wooden plate using a screw. Complete set AK INTERACTIVE Real Colors contains 247 colors (without varnish).
Mounted brackets can be screwed onto the removable back panel.
Dimmension per bracket: approx. 88 x 78 x 25 mm

Wooden frame

In-house construction, closed box with open front, for mounting a roller blind.
Prepared for hanging in the removable back panel.

Roller blind

Made to order.

Print instructions

Material: PLA
Infill: 20%
Nozzle: ø0.4
Layer height: 0,2 mm
Number of half-shells: 2 x 247 = 494 parts
Printing time per half-shell: 1h 5min
Total printing time: 494 parts x 1h 5min = 535h 10min
Weight per half-shell: approx. 0.018 kg
Total weight: approx. 8.9 kg (494 parts)
