Mini 10keys Keyboard

A mini 10 keys keyboard.

Parts :

• 10 key switch. ( Cherry MX or compatible , gateron... )
• 1 Teensy 2
• 10 keycaps ( I printed them ,design will be uploaded soon )
• 4 M4 threaded Inserts
• 4 M4x12 screw
  Software :
  You can use https://github.com/GManzato/qmk\_firmware/tree/master/keyboards/mini10k , it's a fork of the qmk firmware. For now I've just implemented a basic numkey keyboard

Pinout for the Teensy :
Row : F5, F6, F7, B6
cols : F0, F1, F4

Print instructions

Category: Computer Summary

A mini 10 keys keyboard.

Parts :

• 10 key switch. ( Cherry MX or compatible , gateron... )
• 1 Teensy 2
• 10 keycaps ( I printed them ,design will be uploaded soon )
• 4 M4 threaded Inserts
• 4 M4x12 screw
  Software :
  You can use https://github.com/GManzato/qmk\_firmware/tree/master/keyboards/mini10k , it's a fork of the qmk firmware. For now I've just implemented a basic numkey keyboard

Pinout for the Teensy :
Row : F5, F6, F7, B6
cols : F0, F1, F4

Print Settings

Printer Brand:

Ultimaker

Printer:

Ultimaker 2

</div>Rafts:

No

Supports:

No

</div>Resolution:

0.1mm

Infill:

35

</div>

Notes:

I used ColorFabb PLA Black. PLA is quite easy for this project and enough stiff. ABS will be a bit more difficult since you need precise dimensions

Post-Printing

Just add the threaded instert with a soldering iron.
