Mako 69 (3D printable 70% percent keyboard)

Mako 69 V2 is now out!!! Link: https://www.thingiverse.com/thing:4967096

This is my own variation of a DIY mechanical keyboard, it is based on the Mech 104 but I have changed things such as design and more.

This keyboard features 75 keys in total complete with Fn keys.

The one in the photo has a non-working spacebar so I had to redesign it, other than that the entire keyboard works fine.

This keyboard also uses cherry compatible stabilizers such as the Durock V2 plate mounted stabilizers and Cherry compatible switches, such as Gatreon switches.

For the Microcontroller an Arduino Pro Micro will have just enough gpio ports to accommodate all the wiring, it needs in total 20 IO ports. -------------------------- FOR PARTS LIST SCROLL DOWN --------------------- Switches: Cherry compatible switches such as Gatreons (I used these) Stabilizers: Cherry compatible Stabilizers such as Durock V2 Keycaps: Cherry Stem compatible keycaps I used TBKB gray blue keycaps Nuts and bolts: M4 screws such as M412 and M425 (May change so just get 5-6 more than needed) For these M412 you need 4 in total and 2 M425 (May change so just get 5-6 more than needed)

What to print? Download the WHAT_TO _PRINT.txt file and read scroll down to the update log to see what you want to print, the update log will explain most new parts in detail. Note: Some parts are modular so you can choose what type you want.

Additional notes: I will update a better version soon with more screw holes for extra stability and larger pieces, and the ugly side hump will disappear.

In this version I have gotten rid of all logos and text except the Mako 69 plate, their is a blank version for people who want to customize it. Another thing to note is that you can draw up a pattern and print it, then glue it on the extended side piece to decorate it dimensions are included, dimensions are 2.8 by 13.5 cm

THE MAKO 69 SIDE PLATE NEEDS TO BE GLUED ON AND THE BACK SUPPORT

PEICE NEEDS TO ALSO BE GLUED ON AT THE SIDES TO HELP IT STAY IN PLACE.

INFO ON ASSEMBLY:

The Mako 69 side plate needs to be glued on and the screws do not need to go in fully if

you use M4*12 as it will be secure enough

Using videos for help on making your own mechanical keyboard: https://www.youtube.com/watch?v=LVzpsjFWPP4&list=LL&index=2&ab_channel=Matt3o https://www.youtube.com/watchv=BQ5fnELhFeI&list=LL&index=2&ab_channel=StevieBuilds

Print Settings

Printer Brand:

Creality

Printer:

CR10S PRO

Rafts:

No

Supports:

Yes

Resolution:

200

Infill:

5% Gyroid pattern

Filament: ESUN PLA + Blue, Green

Notes:

(⌐■_■)
READ THE UPDATE LOG

Scroll down for update log

Update Log - Please read so you print right thing

Update Log

Mako 69 V2 is now out!!!!
Link:

Update 15 September 2021: Mako 69 V2 is now out with updates, it is incompatible with all Mako v1 stuff.

Update 06 September 2021:

A newer backbone piece is finished it offers more stability and is easier to print, it increases the incline angle by a few degrees and hides the bolt, if you are unsure print this one, it is the safest. I have also uploaded a numpad/macro pad that can be used with this

keyboard. The new support piece will be called BackSupport V2

A macro pad/numpad has been published as an extension or this keyboard. More will follow. A new series called the Mako series will have lots of mods to accompany this keyboard. Saved in my collection, check my profile.

Update 21 August 2021: For me the space bar did not work so then I redesigned the top piece to have a hole, the space bar piece this is so that if the space bar piece does not work I can hammer it out and hammer in a new one. File will be in a zip, parts will start with a S. It should be a tight fit to help hold the part in place do not sand the part unless it seems as if it may crack the frame.

Update 18 August 2021: Middle spacebar piece has been updated an modified as the design did not work for me, File names are still the same but will have a V2 at the end of the name so watch out for it. You can still use the same base as the only that changed is the space bar section. The new back support piece named BackSupport_0 drops the 20 degree tilt to around 5. Newer updates will feature better, stronger pieces. Sound test soon when I finish building it.

This keyboard is modular so read the instructions

As more parts and modules will be coming in the future if you want to recommend something please write it in the comments
