Multifunctional Adjustable Desk Mount for HSW

I really like the adjustable desk mount and the honeycomb storage wall, and it seems like a logical step to combine the two! I provide two different mounting options depending on load/desired rigidity.

Single Slot Mount:

• ArmSwivelBase1xHSW
• ArmSwivelBaseScrew (optional)

This takes up a single slot, and works well for light weight things or short combinations of the arms. I recommend using the double mount for anything > 1 lb, or any combination of 3+ arms. This has the advantage of locking using the same mechanism as the original table clamp (e.g. a set screw). You should be able to use the same screw as the original mount, but due to the print orientation the threads are not as well formed. As a result the original screw may be difficult to use; the screw I include is a recreation of the original, just slightly scaled down.

Double Slot Mount

• ArmSwivelBase2xHSW
• ArmSwivelConnector2x (optional)

This takes up two slots (vertically) and works well for heavier duty tasks. It is significantly more rigid on the wall. It does not have the ability to “lock” in place as I removed the set screw - I didn't feel like it was necessary, and the print orientation makes printing the threads properly difficult. It's not required, but I recommend also printing out the ArmSwivelConnector2x for added strength and stability. It's the original swivel connector with 25mm added to the length.

Recommended Print Settings

• Walls: 4+ walls
• Layer Height: 0.20 mm
• Infill: 30%+ gyroid
• No support for the single slot mount
• Tree supports on the build plate for the double slot mount
