Yellow Excavator version 2 with Movements

To view updated version of this model please click here.

There are three ways to print this.

1. As single piece:- Please download STL file but there wont be any movements.
2. Multiple Pieces :- Download 3mf file with Full_dismantled.3mf.BEST QUALITY OUTPUT. Please use the 3mf file for assembly also. CHECK EASE OF PRINTING TITLE BELOW
3. Combined:- You may use any 3D viewer software like 3D builder in windows to merge components according to your printer and filaments. The sky is the limit for this. You may find a sample file ending with combined.3mf.

EASE OF PRINTING

This model contains parts of 3 colours - GREY, YELLOW, BLACK. I have seperated these into different plates according to colour and in the optimum print position. Please download the folder “Print Plates According to Colour” to make use of them. These plates can be opened in any slicer and printed according to your print profiles.

When you are assembling the globe for rotation, you have to first secure the globe in the undercarriage using the threaded parts and then put a small drop of glue on top of the stock of the sphere to attach the main body. If you at first glue the globe to the main body and then try to secure it to the undercarriage, it will be difficult.

Supports should be provided as required.

Appreciate the makes uploads.Open for suggestions

.

Category: Vehicles

Upgrades From Version 1

The upgrades has been done in the undercarriage and tracks. These were merged in version one now these can be printed seperately and also movement of tracks are also expected when printed in flexible materials. There is now a pin connecting the main arm, earlier the arm had to pushed into the locks. Interferences has been checked and adjusted. Although you would need to be aware of tolerances of your printer.
