Webcam/Phone holder for Prusa Enclosure

Webcam (in this case an old Samsung) orientable holder for the Prusa Enclosure
13
76
2
683
updated August 15, 2023

Description

PDF

Description

I decided to go for an easy solution and recycle an old Samsung to use as Webcam in my new Purse enclosure.

I've used a part of Torpi's screw to create the base support mountable inside the enclosure; I've made it a two screw design for stability and weight holding.

The incredibly well done ball joint by HD_Creator is merged on top of it and I've modified the connection rod to have a screw on both sides (M10 size). The modified hexagonal shape between the screw ends helps in tightening.

I've modified Praik's S8+ holder to be able to screw it on the rod. If you want to mount something different simply change the rod to fit the object you are mounting.

Printing

I've printed it in PETG with 0.2 quality and it works really well. It should print without supports  with the exception of the rod (print in vertical with organic support, it is a beauty to separate).

Happy printing!
