Voron V0.2 handle for 3mm acrylic panels based on BaGooN design with 2 screws fixation
6
37
0
627
updated August 17, 2023

Description

PDF

I remix the super cool design of BaGooN to enlarge the handle by 10mm for my hands.

This design is for Voron V0.2 with 3mm acrylic panels. You have to add one nut into 1515 extrusion to be able to screw the handle (the second nut is already install if you follow the voron official documentation).

You can see the difference between the original design on right side and the remix on left side with the third picture.

Voron recommandations for printing :
- ABS/ASA
- Layer height : 0.2
- Top/bottom : 5/5
- Wall : 4
- Infill : 40%
- Infill type : Grid, Gyroid, Honeycomb, Triangle or Cubic
