Rugged Box for Insta360 One R & GoPro Hero 5 Session

Remixed Model of the legendary “Rugged Box (Parametric)” by user Whity.

I made some custom inlay to fit the following:

• 1x GoPro Hero 5 Session (with Frame)
• 1x Insta360 One R (with Frame and Lens Cover)
• 1x USB-C Charging Cable
• some loose mounting equipment

For assembly you will need 6  M3x30 Bolts which will be flush with the hinges.
If you want to use nuts on the other end you'll need longer bolts of course.

My box was Printed on a BambuLab X1C with the 0.20mm standard Profile utilising the AMS in the following filaments:

• Prusament PETG Galaxy Black for the Bottom and the Lid
• Prusament PETG Signal White for the Logos and
• Prusament PETG Prusa Orange for the Latches

Since I have no TPU yet, it didn't print the seal but the box worked great anyway.

Happy printing :)

****** EDIT ********

05.07.2023
Added an inner lip for seal placement on the Bottom part (V1.1). I missed to extrude it in V1.
