Laptop mount: behind the monitor (VESA 100/75)

Smaller, faster to print version of underrated laptop mount that helps to keep the desk really tidy!
31
235
2
2575
updated August 3, 2023

Description

PDF

I was looking for ideas to cleanup the desk a bit and found a great model for attaching laptop behind a monitor using VESA shelf. Unfortunately I'm very impatient and once I've seen the 18 hours print time of original model and amount of used filament I decided to make it more efficient.

Hopefully it'll be useful to someone ;)

Properties:

  • 30 mm thick laptops support (33.5mm gap)
  • VESA 100x100 / 75x75

Print guidelines

These might not be the best you can do - feel free to experiment a bit.

It printed in ~5 hours on my Ender 3 V2 Neo.
(4h 40m Prusa Slicer estimation, compared to 18 hours for original version)

  • Nozzle: 0.4mm
  • Layer height: 0.2mm
  • Perimeters: 3x0.48mm
  • Top/bottom layers: 4
  • Infill: Cubic, 20% with 2mm anchoring
  • Material: PETG
  • Cooling: low to improve strength

Changes:

  • Reduced width (138mm → 33mm)
  • Stronger inside-outside connection
  • More cable holders

Tags



Model origin

The user re-uploaded this model. The user is not the original author of the model.

Laptop VESA mount shelf
by Bader
It is not allowed to upload a model that already exists on Printables.

License
