Standup Paddle Board - SUP Handle

This SUP handle allows one handed movement of a SUP. You can put your SUP on the roof of your car with one hand or lift it from an awkward position.

Included are STLs for installation jigs and bases for a Makita RT0701C Router ( for 1/4" and 3/8" straight bits). There are alternate files to compensate for slight variances in router bit sizes or printing tolerances. Test them all in scrap foam to see what works best for you.

If you don't have that router you can use a Dremel or other rotary tool and eye ball it if you are just doing one installation.

I have printed in both ASA and PETG, ASA can have warping issues on the base but I've had good success. PETG is my preferred filament and epoxy resin or polyester resin sticks to both filaments very well. PLA is probably ok but I wanted maximum durability so ASA or PETG is the way to go. Clean with acetone and install with resin and a mix of glass microbeads or cabosil, then fiberglass over the top of the handle, and cut open the openings once resin is set.

I recommend printing the handle in two parts and gluing them together with either ASA paste (make with acetone and ASA) or epoxy of you are using PETG, rough the surfaces well.

100% infill with supports on.

Not exact instructions on how to use the jigs but you get the idea from my website https://www.geckosurfboards.com/surfboard-building-router-jigs/
