Ikea Helmer Tray

This is a basic top tray for the Ikea Helmer. It sits on the top of the drawer and slides back and forth as needed.

It is just large enough that it cannot be printed horizontally in the Creality Ender 3 V2, so I had to print it standing vertically with Cura 5.4's revised tree support system. This actually made it incredibly easy to peel away the trees once printed. I used 3 walls with no infill, 0.28 resolution.

With Prusa Mk3s+ printer you can print horizontally with minimal support for the overhangs.

Takes about 110g of filament to make.

The F3D file is included if you wanted to change the dimensions or print it in two pieces (for gluing together) if you find that to be easier.
