2020 20x24 bracket

A right angled bracket for 2020 extrusions with length of 20mm on one side and 24 on the other.
5
30
0
120
updated July 9, 2023

Description

PDF

A right angled bracket for 2020 extrusions with length of 20mm on one side and 24 on the other.

M5 C'Bored thru holes on each side are aligned so the facing extrusion will be colinear to the outer faces.

Print with either face down. Supports should not be needed.
