EDI Mech Warrior Elastic Band Shooting Robot with EZ-Bits

Inspired by Mech Warrior games, this two legged robot is armed with an elastic band turret. The parts of this robot clip together to build different configurations, if you wish. However, I'm confident that you will love EDI just the way he is! The turret loads elastic bands, which you can fire at your pet, targets or friends.

See this robot in action here: https://youtu.be/nRkC216djdA

Print Settings

Rafts:

Yes

Supports:

Yes

Infill:

30

Filament:

Canadian Filaments PLA

Notes:

Here is how the parts clip together: https://youtu.be/Rm4H5y_RLVY

The servo mounting holes can be difficult to fit onto the servo output gears. Here's a tutorial to help you along the way: https://synthiam.com/Community/Tutorials/Strengthen-Servo-Splines-in-3D-Printed-Brackets-17948

The servos used in this robot's legs are here: https://www.ez-robot.com/store/p16/servo-motor/Heavy-Duty-Servo-Motor/DIY-Servo-Motor.html

The camera for the head is here: https://www.ez-robot.com/store/p64/robotics-camera.html

The EZ-Bv4 all-in-one Robot Controller Brain is here: https://www.ez-robot.com/store/p24/EZB-smart-robot-controller.html

The LiPo battery is here: https://www.ez-robot.com/store/p25/robot-power/lipo-battery.html

The internal wiring harness + power switch is here: https://www.ez-robot.com/store/p89/wiring-harness-short.html

The iOS and Android App can be downloaded here: https://www.ez-robot.com/mobile-robot-software.html

Windows software for programming this robot can be found here: https://www.ez-robot.com/pc-robot-software.html
