Voron 2.4 tophat with integrated touchscreen

update 2023/07/09:

• moved the mounting tabs a bit outwards to make the “sturdy handles” fit between them (surely not on the 250 xD)
• added versions for the 250/350 (not tested, only adjusted by +/- 50mm)
• added a test object for the display
• lots of small things

A 4-piece tophat for the Voron 2.4 (and maybe others, like the trident).

Made for and tested on the 300mm version and then simply adjusted by +/- 50mm.

Why?

• a lot more Space at the top, now mine can move over 300mm high
• more stiffness (nevertheless, no difference in resonance measurement)
• integrated touchscreen (if you dont want it, printing the rear left part four times should also work)
• holes for 6x3mm Magnets to hold the panel
• holes for thread inserts at the bottom to mount fancy stuff
• printable on the printer to be mounted on
• stealth look (a bit)
• integrated channel for the ribbon cable

BOM:

• 4.3" Waveshare touchscreen
• 8x M5x8 BHCS
• 8x M5 roll-in-nuts or T-nuts
• 16x M3 Thread inserts
• 16x M3 Washer
• 16x M3x10 BHCS
• 4x M2,5x8 Screws (for the Display)
• 2x 5x18 dowel pin
• 330x330x5mm acrylic panel
• ~1kg Filament (PLA)
• foam tape
