Clip to arrest an M.2 NVME-SSD in the ASUS PRIME B450M-K II

The mainboard does not seem to come with a Clip to arrest the M.2 Disk Drive in it's slot - Here it is!
10
220
0
1223
updated June 3, 2023

Description

PDF

The mainboard does not seem to come with a Clip to arrest the M.2 Disk Drive in it's NVME slot - in case you need one: here's an option.

Lock the holder on the bottom side of the mainboard by adding a regular metal M4 thread nut on top of the printed shim, arrest the M.2 drive on the top side of the mainboard with a small self tapping screw - done. Be careful in case you print in PLA as the printed thread does not accept too much force.
