Toyota MR2 SW20 Works Bell Hub Cruise Control Stalk Bracket/Adapter

This is a bracket that sandwiches between your steering wheel hub and quick release hub/steering wheel to remount your cruise control stalk. This was designed with a Works Bell Rapfix Short Hub (520S) so I can only guarantee fitment for that.

Requires x3 M5-0.80 x 20mm screws and x3 nuts to attach the stalk to this bracket.

The connector on the cruise control stalk is also too large to fit through the wiring hole in the Works Bell hub so I had to pull all the wires with pins out and pull those through before putting the pins back into the connector then connecting it to the clock spring.

I printed using ASA but had prototypes printed in PETG and because of PETG's compliance it was a bit too flexible so I recommend using ASA or a similarly rigid material for this. Recommend minimum 4 walls and 25%+ infill for rigidity.
