Antenna balun / unun case (ham radio)

Case for antenna balun or unun.
13
58
0
899
updated May 18, 2023

Description

PDF

Hello! This is a case to fit antenna baluns you either bought or create. In my case, I bought the balun from Funkfieber for QRP operations.

  • 89mm long x 44mm width x 37mm height
  • 3 x 6.5mm holes (for banana type female connector and earing as holder)
  • 1 x 13mm hole (to fit a BNC plug)

Feel free to provide feedback in case I need to adjust something to it. 73!
