Extension for ezidri dehydrator - Humidity Meter

Remixed to add humidity meter & holder for PTFE tube to have measurement from the inside of the Ezidry volume.

Humidity meter should be a bit modified to allow insertion of PTFE tube inside the case. If you are accurate enough, do not disassemble meter, just cut two thin pieces of plastic grill with eXacto knife and make a round hole.

Note: Sensor itself is a white 6x6mm ceramic plate, it's right behind the small grill at the right-top corner on the back of the humidity meter. If you cut carefully with the very point of the knife, you can not damage it easily.

PTFE holder piece should be glued or "chemically welded" via dichloroethane/dichloromethane (careful here, vapor t's poisonous!)

I recommend 5mm PTFE (outer diameter, 3mm inner) - less cuts are to be made and more airflow is allowed to humidity sensor.

Length of the PTFE tube can vary, and depends on where you need to measure humidity.

Print Settings

Printer Brand:

Flying Bear

Printer:

Flying Bear Ghost 5

Rafts:

No

Supports:

Yes

Resolution:

0.2mm

Infill:

15-20%

Filament: SUNLU ABS (preferably), PETG White
