Stiffer X-End for Prusa Mini with tension screw
Added a screw for easy tension adjustment.
15
44
1
411
updated January 21, 2024
Description
PDFIt's difficult to adjust the tension when it's in an enclosure, so I added a screw so that you can easily adjust the tension even if there's a wall on the left.
Requires a DIN562 M3 square nut like the original mod.
October 16, 2023 Data has been slightly revised. If you print the screw size as is, it should be fine.
January 14, 2024 The retainer's XZ-axis adjustment screw hole was returned.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Changed so that belt tension can be easily adjusted.
