Utrasonic sensor HC-SR04 holder

This ultrasonic adapter helps to securely hold the HC-SR04 ultrasonic sensor in place for any use.
1h 20m
1× print file
0.20 mm
0.40 mm
12.00 g
5
33
0
236
updated May 11, 2023

Description

PDF

Hello, I'm uploading my own version of an ultrasonic HC-SR04 sensor holder. This design has a tight fit, so please be careful when inserting the sensor.

To print, please place the gadget in the orientation shown in the photos. This will help to minimize any imperfections on the part where the sensor will be placed. Additionally, supports on the building plate need to be placed due to the overhang. Please add a brim to make sure that the print will not loosen during the print. If you want the infill to be visible, remove the top and bottom layers. The results should be similar to what is seen in the images.

If you have any questions on how to print it properly, please let me know in the comments!
