To be used if you have a wobbly bed
25
94
2
1133
updated May 10, 2023

Description

PDF

So my bed had a bit of a wobble from a bad linear rail block, so I replaced the block, problem was the replacement was just as bad as the first one. Or my rail has some really bad machining. Anyway to avoid spending more I designed this.

*It works for my machine but tolerances may differ between machines.*

It clicks on snuggly and the Bearing Wheel is press fit.

I just printed it in PLA+ for prototyping but it's holding up fine, I only use this machine for pla so my bed doesn't go over 60, but perhaps you might consider printing in abs/asa/petg if your bed is going over 60.

Oh and the clip goes on top :)
