Mini box with cover for particle Photon / Core with breadboard

Pretty minimalistic box to hold a small breadboard and a photon / spark core with room for some other components.…
3
42
0
304
updated May 8, 2023

Description

PDF

Pretty minimalistic box to hold a small breadboard and a photon / spark core with room for some other components.

Printed with no supports, there's a few bridges but they are small enough to cause no trouble.

There are two lids on this 'thing' one (v1) is really flush with the photon and the other (v2) allows to have more space inside the box.

Sliced inCURA with the following settings:

  • Nozzle size: 0.4mm
  • Layer height: 0.25mm
  • No supports
  • Infill: 20%
  • Speed: 40mm/s

Took around 30 min for the box and 12 min for the lid

Category: Electronics
