Stealthburner Clockwork 2 - SB2040

Dual Filament Sensors- Larger door (With Fan) for SB2040 - M10 Passthrough
18
137
0
2023
updated May 6, 2023

Description

PDF

Am sure anyone with a Stealthburner with any toolboard especialy the FLYSB2040 has foind it is a pain to get access to the connectors. So I remixed the great door mod by Alexander Þór 🇮🇸🇬🇧, I have also added another sensor to the one released by Leiwandizer. This is for people who cannot decide or having problems with sensorless on the ERFC. Have yet to finish building. Instead of using 5mm bearings i used 4.5, it is modeled for a 5mm (dia 5.4mm hole), depending on how dialed in your machine is you may just need to twist in a drill to remove any bits.

I have also moved the filament path to allow for an M10 Pass through, aprox 9mm into the extruder, its a nice clean path all the way through to the Hot end



Print at voron recomended settings, no supports

You will need Omron D2F-01L, 2 Screws for each (same as you get on V0 endstops)

4.5mm or 5mm Bearing



Enjoy
