Railcore Cable Loom Angled PTFE tube holder for M10 (1/8 BSP) fitting

Update, May 3, 2020

The previous version of this part had an issue where the ptfe tube could ratchet through the fitting during a print, shortening the overall wire bundle and thus causing skipped steps or breakage.

The printed part now captures the bowden tube, so it cannot pass through anymore.

Note, a lot of the M10 pneumatic coupler fittings that are sold are actually threaded 1/8" BSP. The printed part is threaded for 1/8" BSP.

This combines pneumatic M10 bowden tube fitting and cable loom holder for the railcore.

No supports necessary, and the M10 fitting is designed to thread into the printed part. Print at 0.15mm layer height for better threads.
