Series 4 Apple Watch Charger

UPDATED! Larger USB opening *Apple changed the USB cable at some point to make them larger so I increased the size substantially. Sorry for all who had issues with this.*

This charging stand is designed specifically for the 44mm Series 4 Apple Watch.

So far there are two versions, one with the Apple logo and one without.

If you'd like me to include a version for the series 0-3 watches let me know in the comments.

The design has fairly tight tolerances in terms of the fit with the charging puck. It should snap into place perfectly but it will take a little squeezing. To remove the charging puck, insert a pen/pencil/chopstick up through the hole in the bottom and push it out.

If you have time to post a make, I’d really appreciate it, I love to see them! My favorite part of sharing my designs is seeing the makes!

If you like this thing, check out my other designs!

Print Settings

Printer Brand:

Monoprice

Printer:

Select Mini

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.175mm

Infill:

20%

Filament: Hatchbox PLA with Wood fiber

Notes:

Printed at 200C nozzle temp and 50C bed temp. My bed is PEI on glass.
40mm/s print speed

This material is my new favourite. If you haven't tried printing with wood PLA, buy a spool!

How I Designed This

Designed in Fusion 360
