StageTop Frame and Tile Lock Multitool with Variations Including Leg Lock (UPDATED)

This is a really quick and easy tool to help you remove/install the frame locks. It has imprints in 2 directions so it works both at 0 and 90 degrees. The spacing has been scaled up 3% from the original frame locks so regardless of your printer it should fit over nicely.

UPDATE:

V2 - I added the tile lock feature on both ends of the tool as well as compressed things a bit and shaved off the sides to both provide an easier grip and to reduce filament use and print time.

I printed with 3 walls and 10% gyroid infill in PLA. The angle of the sides is 55 degrees.


UPDATE:

V3 - A request was asked on Facebook to modify this tool to support the short leg lock because it doesn't have a lot of grip to twist it by hand. This version has a more rounded handle with finger grips, a more narrow head, the tile lock on the end, a longer and shorter version of the handle.

Because why not, I also added a few other versions so people can choose what they like best. Personally the finger grips are nice but I am more of a fan of the angled cut handle shorter version.

NOTE: If you are going to use the Leg Lock version with the longer handle you will only be able to twist it on about 80% of the way, if you want to be able to twist it 100% then use the shorter handle version.
