SBox & SBox Mini Axis Pin Cutting Guide

SBox & SBox Mini call for several metal axis of various lengths.  This jig will help measure and identify where to cut 2.8 - 3mm rod.

Lengths are 39mm, 36mm, 26mm, 24mm, & 22mm.

Just insert rod and cut a front face - I used a Dremel cutting wheel. Afterwards used Dremel Sanding Disc to smooth the freshly cut pin edges.

Original design did not include 22mm length - it is now added even though the picture show the 1st version with 4 lengths.

When printing the 1st version - filament swap did not go smoothly due to operator error and the text did not print in another color but Jig was still useable so didn't bother to reprint.
