GLEDOPTO Cover

This is a cover for a GLEDOPTO Zigbee LED controller

I have a GLEDOPTO Zigbee LED controller which I am using to control a LED strip under the couch.

One end of the GLEDOPTO controller has a barrel jack for 12v input.

The other end has push in connectors for the output. I have always found the push in connectors a little unreliable and can easily come out so I made this small cover.

The cover would also work perfectly on the input side.if you were not using the barrel jack.

It press fits over the back of the controller and protects the output cables.

Press fit is perfectly tight printed at .10 on a prusa MK3. You could always print it at 101% and use some electrical tape to snug up the joins.

The GLEDOPTO controller I have is 47.8mm x 23.8mm

I have a second version of the model which is slightly deeper and includes little bumps to lock into the controllers wire holes on the top. (Its specifically made for the WW/CW version of the controller. I have not tested this version as my initial version worked well enough for me.

Please leave a comment if you successfully make this!

Print Settings

Printer Brand:

Prusa

Printer:

I3 MK3S

Rafts:

Doesn't Matter

Supports:

No

Resolution:

.10mm or .20mm should be fine

Infill:

15%

Filament: Generic PLA or PETG - White (Match the GLEDOPTO box)
